Yamaha V-Star 950 (2009-2012) Repair Manual Clymer Reparaturanleitung

This Yamaha V-Star 950 manual is 360 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers and information labels / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications Specs

CHAPTER TWO / TROUBLESHOOTING
Starting the engine / Engine does not start / Poor engine performance / Fuel system / Electronic diagnostic system / Charging system / Ignition system troubleshooting / Starter system troubleshooting / Engine / Engine lubrication / Cylinder leakdown test / Clutch / Gearshift linkage / Transmission / Electrical testing / Lighting and signal system troubleshooting / Front suspension and steering / Brake system / Specifications Specs

CHAPTER THREE / LUBRICATION, MAINTENANCE and TUNE-UP
Tune-up / Engine rotation / Air filter / Crankcase breather hose inspection / Spark plugs / Ignition timing / Valve clearance / Engine compression test / Engine idle speed inspection / Throttle body synchronization / Fuel system hose inspection / Carbon canister (California models) / Throttle cables and grip / Clutch cable and clutch lever / Engine oil and filter / Engine oil pressure test / Battery / Exhaust system / Shift pedal / Sidestand / Drive belt / Tires and wheels / Steering bearings / Front fork / Front fork oil change / Shock absorber / Swing arm and rear suspension / Chassis, engine and frame fasteners / Brakes / Headlight aim / Horn, lights and turn signals / Specifications Specs

CHAPTER FOUR / ENGINE TOP END
Camshafts / Rocker arms and shafts / Cam chains and guides / Cylinder head / Valves and valve components / Cylinder / Piston and piston rings / Cylinder stud replacement / Specifications Specs

CHAPTER FIVE / ENGINE LOWER END
Servicing engine in frame / Engine / Crankcase / Crankcase seal and bearing replacement / Crankshaft / Connecting rods / Oil pump / Engine break-in / Specifications Specs

CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM
Right crankcase cover / Oil passage oil seal replacement / Clutch release shaft / Clutch / Primary drive gear / External shift mechanism / Clutch cable replacement / Specifications Specs

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM
Transmission / Internal gearshift mechanism / Specifications Specs

CHAPTER EIGHT / FUEL INJECTION SYSTEM
Fuel injection (FI) / Fuel delivery system tests / Fuel tank / Fuel pump / Fuel sender / Fuel pump relay / Air filter housing / Throttle body / Intake manifold / Pressure regulator, fuel injectors and fuel rail / Idle speed control (ISC) unit / Throttle position sensor (TPS) / Engine control unit (ECU) / Intake air pressure (IAP) sensor / Air temperature sensor / Engine temperature sensor / Crankshaft position (CKP) sensor / Lean-angle sensor / 02 sensor / Rollover valve / EVAP canister / Throttle cable replacement / Specifications Specs

CHAPTER NINE / ELECTRICAL SYSTEM
Electrical component replacement / Electrical connectors / Battery / Battery box / Charging system / Regulator/rectifier / Left crankcase cover, stator coil / and crankshaft position sensor / Flywheel, starter clutch / and starter clutch gears / Ignition system / Ignition coils / Ignition coil mounting bracket / Crankshaft position (CKP) sensor / Lean angle sensor / Engine control unit (ECU) / Ignition timing / Ignition system diode / Starter / Starter relay switch / Starting circuit cut-off relay / Starting system diode / Lighting system / Headlight / Turn signals / License plate light / Tail/brake light / Indicator light replacement / Meter assembly / Lighting system troubleshooting / Signal system troubleshooting / Speed sensor / Oil level warning light and oil level switch / Relay unit / Diode test / Switches / Horn / Fuses / Wiring diagrams / Specifications Specs

CHAPTER TEN / WHEELS, TIRES, DRIVE BELT AND PULLEYS
Motorcycle lift / Front wheel / Rear wheel / Front and rear hubs / Drive hub / Wheel service / Tire changing / Wheel balance / Outer drive pulley cover / Drive belt / Drive pulley / Inner drive pulley cover / Driven pulley / Specifications Specs

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Handlebar / Handlebar grips / Front fork / Steering head and stem / Steering head bearing race replacement / Steering stem bearing race replacement / Specifications Specs

CHAPTER TWELVE / REAR SUSPENSION
Shock absorber / Connecting rods and relay arm / Rear swing arm / Specifications Specs

CHAPTER THIRTEEN / BRAKES
Brake service / Brake bleeding / Brake fluid draining and flushing / Brake pads / Front brake caliper / Front master cylinder / Rear brake caliper / Rear master cylinder and brake pedal / Brake hoses / Brake disc / Specifications Specs

CHAPTER FOURTEEN / BODY AND EXHAUST
Seats / Side covers / Cylinder head side cover / Cylinder head plastic covers / and mounting brackets / Right side lower cover / Left footrest, shift pedal and shift rod / Right footrest / Sidestand / Windshield and mounting brackets / Saddlebags and bracket / Front fender / Rear fender / Exhaust system / Specifications Specs

INDEX

COLOR WIRING DIAGRAMS

Clymer Reparaturanleitungen zählen zu den erfolgreichsten auf dem Markt und sind sowohl für Hobbyschrauber als auch für Mechaniker der unverzichtbare Ratgeber bei allen Fahrzeugreparaturen. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

Written from hands-on experience gained from the complete strip-down and rebuild of the car, Clymer can help you understand, care for and repair your car. We do it ourselves to help you do-it-yourself, and whatever your mechanical ability, the practical step-by-step explanations, linked to over 900 photos, will help you get the job done right. Regular servicing and maintenance can help maintain its resale value, save you money, and make it safer to drive.

Sprache: Englisch

Gerne stellen wir Ihnen beim Kauf dieses Artikels das 32-seitige technische Wörterbuch von Haynes (englisch/deutsch) als Download zur Verfügung.
