Yamaha V-Star 1100 (99 -09) Repair Manual Clymer Reparaturanleitung
| eTitel | Yamaha V-Star 1100 (99 -09) Repair Manual Clymer Reparaturanleitung |
|---|---|
| Seitenzahl | 403 |
| Artikelzustand | Neu |
| Artikelart | Reparaturanleitung |
| Sprache | Englisch |
| Druckvariante Printversion | Printversion in S/W |
| Hersteller | Yamaha |
| Modelle | XVS1100 XVS1100 Custom Models (2000-2009) XVS1100A Classic Models (2000-2009) |
| Baujahre | 1999 - 2009 |
| Verlag | Clymer Service Manuals |
Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.
CHAPTER TWO / TROUBLESHOOTING
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance intervals schedule/ Tune-up / Spark plugs / Engine oil / Control cables
CHAPTER FOUR / ENGINE TOP END
Cylinder head / Camshaft / Rocker arms / Cam chain and cam chain drive assembly / Valves and components / Cylinder / Pistons and rings
CHAPTER FIVE / ENGINE LOWER END
Removal installation / Alternator cover / Stator and pickup coils / Flywheel and starter clutch / Oil pump / Crankcase / Crankshaft / Connecting rods / Break-in / Connecting rod bearing insert selection
CHAPTER SIX / CLUTCH AND PRIMARY DRIVE GEAR
Clutch cover / Release mechanism / Cable replacement / Primary drive gear
CHAPTER SEVEN / TRANSMISSION, SHIFT MECHANISM AND MIDDLE GEAR
Shift pedal / Footrest / External and internal shift mechanism / Transmission / Middle drive and driven shaft / Checking middle gear backlash
CHAPTER EIGHT / AIR / FUEL, EXHAUST AND EMISSION CONTROL SYSTEMS
Fuel tank / Fuel valve / Air filter housing / Surge tank / Carburetor / Pilot screw / Fuel level / Idle speed adjustment / Throttle cable adjustment / Throttle position sensor / Fuel cut solenoid valve / Carb heater / Throttle cable / Choke cable / Fuel filter / Fuel pump / Air induction system / Evaporative emission control (California models)
CHAPTER NINE / ELECTRICAL SYSTEM
Charging system / Stator / Voltage regulator / Rectifier / Ignition system / Spark plug cap / Ignition coil / Pickup coil / Diode / Ignitor unit / Starting system / Starter / Starting circuit cutoff relay / Starter relay / Lighting system / Headlight / Meter assembly / Taillight / brake light / Signal system / Horn / Turn signals / Neutral indicator light / Oil level indicator light / Speed sensor / Switches / Self-diagnostic system / Fuses / Wiring connectors / Bulbs
CHAPTER TEN / WHEEL AND TIRES
Motorcycle stand / Brake rotor protection / Wheel inspection / Bearing removal / Bearing installation / Front and rear wheel / Rear hub / Laced wheel service / Wheel balance / Tire changing
CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Front fork / Handlebar / Steering head / Bearing races / Lower bearing
CHAPTER TWELVE / REAR SUSPENSION AND FINAL DRIVE
Shock absorber / Suspension linkage / Swing arm / Final drive assembly
CHAPTER THIRTEEN / BRAKES
Brake service / Preventing brake fluid damage / Brake bleeding / Brake fluid draining / Brake pads / Front and rear caliper / Front and rear master cylinder / Brake pedal / Brake disc / Brake hose replacement
CHAPTER FOURTEEN / FRAME
Seats / Ignitor panel / Left side cover / Toolbox cover / Toolbox panel / Battery cover / Right side cover / Battery box / Frame neck cover / Rider floorboards / Passenger footpegs / Sidestand / Front fender / Rear fender / Windshield
COLOR WIRING DIAGRAMS
