Yamaha Snowmobile (97-02) - Shop Manual

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Gasket remover / Expendable supplies / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Testing electrical components / Ignition electrical components / Battery charging system (models with electric start) / Lighting system / Electric starting system / Fuel system / Engine / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Break-in / Correct fuel mixing / Maintenance schedule intervals / Engine oil tank change / Chaincase oil change / Spindle lubrication / Slide suspension lubrication / Speedometer drive adapter / Cooling system / Coolant level check change inspection / Daily maintenance / Drive belt check / Headlight taillight check / Steering bolt / Carburetor jetting / Weekly maintenance / Recoil starter / Ski and runner alignment / Track adjustment / Fuel filter / Water pump belt / Drive chain reverse gear / Cylinder head torque / Tune-up / Compression check / Two-stroke pressure test / Cylinder head torque / Spark plug plugs / Ignition timing / Dynamic timing / Static timing / Carburetor synchronization / Idle speed / Specifications

CHAPTER FOUR / ENGINE
Engine and chassis serial numbers / Engine removal installation / Engine plate and mounts / Engine top end / Cylinder head / Cylinder housing / Pistons / Piston rings / Wrist pins / Connecting rods / Small end bearings / Reed valve / Crankcase / Crankshaft / Pinion gear / Specifications

CHAPTER FIVE / FUEL AND EXHAUST SYSTEMS
Air box / Intake tubes / Carburetor / Carb heating system / Fuel Pump / Fuel tank / Fuel valve / Throttle cable / Exhaust / Specifications

CHAPTER SIX / ELECTRICAL SYSTEM
Flywheel and stator / Battery / Ignition coil coils / Capacitor discharge ignition CDI / CDI control unit / CDI Box / Voltage regulator / Lighting system / Instrument cluster gauges / Switches / Fuel level sensor / Oil level indicator / Electric starter system / Circuit breaker / Hand warmers / Wiring diagrams / Specification

CHAPTER SEVEN / OIL INJECTION SYSTEM
Oil pump / Specification

CHAPTER EIGHT / COOLING SYSTEM
Coolant pump / Heat exchanger / / Hoses / Specifications

CHAPTER NINE / RECOIL STARTER

CHAPTER TEN / DRIVE SYSTEM
Drive unit / Primary sheave / Secondary sheave / Drive belt / Specifications

CHAPTER ELEVEN / BRAKES
Hydraulic brake pad replacement / Brake caliper / Master cylinder / Parking brake / Brake hose / Brake disc / Bleeding / Specifications

CHAPTER TWELVE / CHAINCASE, JACKSHAFT AND FRONT AXLE
Drive chain and sprockets / Chaincase / Jackshaft / Front axle / Specifications

CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Shock absorbers / Steering assembly / Handlebar handle bar and grips / Specifications

CHAPTER FOURTEEN- / AND REAR SUSPENSION
Rear suspension / Wear strips / End caps / Shock absorbers / Track / Specifications

CHAPTER SEVENTEEN / OFF SEASON STORAGE
