Yamaha Royal Star (1996-2010) Repair Manual Clymer Reparaturanleitung

This Yamaha Royal Star manual is 536 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Precision measuring tools / Electrical system fundamentals / Special tools / Basic service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Engine principles / Operating requirements / Starting the engine / Starting difficulties / Engine performance / Engine noises / Engine lubrication / Engine leakdown test / Clutch / Gearshift linkage / Transmission / Final drive / Carburetor / Fuel pump / Carburetor heater / Electrical test equipment / Basic electrical test procedures / Electrical systems / Self-diagnostic system / Engine indicator light (all models) / SET/RES lights (XVZ13TF models) / Cruise control / Audio system (XVZ13TF models) / Front suspension and steering / Brake system / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance intervals / Periodic lubrication / Engine oil and filter change / Engine oil pressure test / Battery / Tune-up / Air filter / Spark plugs / Engine compression test / Ignition timing / Valve clearance adjustment / Specifications

CHAPTER FOUR / ENGINE TOP END
Servicing engine in the frame / Cylinder head covers / Camshafts / Cylinder heads / Valves and valve components / Specifications

CHAPTER FIVE / ENGINE LOWER END
Servicing engine in the frame / Engine removal and installation / Cylinder covers / Crankcase breather cover / Alternator cover / Stator and pickup coils / Flywheel / Starter clutch / Starter gears / Oil pan / Oil pump / Main oil gallery / Piston/connecting rod assembly / Pistons and piston rings / Crankcase / Crankshaft and cam chain / Balancer shaft (XVZ13TF models) / Break-in / Specifications

CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM
Bleeding / Fluid draining / Clutch cover / Master slave cylinder / Floorboard shift pedal assembly / External shift mechanism / Clutch hose replacement / Specifications

CHAPTER SEVEN / TRANSMISSION, MIDDLE GEAR AND INTERNAL SHIFT MECHANISM
Internal shift mechanism / Middle gearcase cover / Middle drive gear assembly / Middle driven gear assembly / Specifications

CHAPTER EIGHT / AIR/FUEL, EMISSION CONTROL AND EXHAUST SYSTEMS
Fuel tank / Fuel valve / Fuel filter / Fuel pump / Air filter housing / Surge tank / Carburetor operation / Carburetor / Cleaning, inspection and adjustment / Pilot screw / Throttle position sensor TPS / Carburetor heater system / Throttle cable / Air induction system / Evaporative emission control / Exhaust system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Electrical connector identification / Battery negative terminal / Charging system / Stator / Voltage regulator rectifier / Ignition system / Ignition coil / Pickup coil / Spark plug / Igniter unit / Starting circuit cutoff relay / Starting system / Starter / Starter relay / Headlight / Meter assembly / Taillight / Brake light / Neutral indicator light / Turn signals / Flasher relay / Horn / Indicator lights / Cruise control / Audio system / Switches / Speed sensor circuit continuity / Fuses / Specifications

CHAPTER TEN / COOLING SYSTEM
Hoses and clamps / Cooling system check / Water pump / Coolant reservoir / Radiator / Fan motor assembly / Thermo unit / Thermostat housing / Thermoswitch / Specifications

CHAPTER ELEVEN / WHEELS AND TIRES
Motorcycle stand / Brake rotor protection / Wheel inspection / Front wheel / Front hub / Rear wheel / Rear hub / Wheel balance / Tire repair / Tire changing / Specifications

CHAPTER TWELVE / FRONT SUSPENSION AND STEERING
Front fork / Handlebar / Grip replacement / Steering head / Steering head bearing races / Lower bearing inner race replacement / Specifications

CHAPTER THIRTEEN / REAR SUSPENSION
Shock absorber / Relay arm / Swing arm / Final gearcase / Specifications

CHAPTER FOURTEEN / BRAKES
Brake service / Brake bleeding and draining / Brake pad replacement / Front brake caliper / Front brake master cylinder / Rear brake caliper / Rear brake master cylinder / Floorboard brake pedal assembly / Brake disc / Brake hose replacement / Specifications

CHAPTER FIFTEEN / FRAME
Rider floorboard / Passenger floorboard / Passenger footpeg / Footrest panel / Side cover / Inner cover / Frame neck cover / Seats / Front fender / Rear fender / Saddlebags / Saddlebag guidebars / Trunk / Lower cover / Specifications

Clymer Reparaturanleitungen zählen zu den erfolgreichsten auf dem Markt und sind sowohl für Hobbyschrauber als auch für Mechaniker der unverzichtbare Ratgeber bei allen Fahrzeugreparaturen. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

Written from hands-on experience gained from the complete strip-down and rebuild of the car, Clymer can help you understand, care for and repair your car. We do it ourselves to help you do-it-yourself, and whatever your mechanical ability, the practical step-by-step explanations, linked to over 900 photos, will help you get the job done right. Regular servicing and maintenance can help maintain its resale value, save you money, and make it safer to drive.

Sprache: Englisch

Gerne stellen wir Ihnen beim Kauf dieses Artikels das 32-seitige technische Wörterbuch von Haynes (englisch/deutsch) als Download zur Verfügung.
