Yamaha 115 - 250 HP Two-Stroke Outboard and Jet Drives (99-02) Clymer Owners Marine Service & Repair Manual
| eTitel | Yamaha 115 - 250 HP Two-Stroke Outboard & Jet Drives (99-02) Clymer Manual |
|---|---|
| Seitenzahl | 504 |
| Artikelzustand | Neu |
| Artikelart | Reparaturanleitung |
| Sprache | Englisch, incl.Gratis Wörterbuch |
| Hersteller | Yamaha |
| Modelle | ● Yamaha 115 HP (1999-2002) ● Yamaha 130 HP (1999-2002) ● Yamaha 150 HP (1999-2002) ● Yamaha 175 HP (1999-2002) ● Yamaha 200 HP 2.6L (1999-2002) ● Yamaha 200 HP 3.1L (1999-2002) ● Yamaha 225 HP 3.1L (1999-2002) ● Yamaha 225 HP 3.3L (1999-2002) ● Yamaha 250 HP 3.1L (1999-2002) ● Yamaha 250 HP 3.3L (1999-2002) ● Yamaha 80 Jet (1999-2002) ● Yamaha 105 Jet (1999-2002) |
| Baujahre | 1999-2002 |
| Verlag | Clymer Service Manuals |
| Behandelte Reparaturgruppe | Gesamtes Fahrzeug |
Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.
QUICK REFERENCE DATA
CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Model identification / Engine operation / Fasteners / Shop supplies / Galvanic corrosion / Propellers / Basic tools / Special tools / Precision measuring tools / Electrical system fundamentals / Basic mechanical skills / Specifications
CHAPTER TWO / TROUBLESHOOTING
Preliminary inspection / Operating requirements / Starting difficulty / Starting system / Charging system / Fuse and wire harness / Warning system / Ignition system / Fuel system (carburetor equipped models) / Fuel system (EFI and HPDI models) / Electronic control system (EFI and HPDI) / Oil injection system / Tilt and trim system / Power head / Cooling system / Gearcase / Specifications
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Lubrication / Oil recommendations / Premix models / Oil injection models / Gearcase lubrication / Gearcase lubricant level check / Gearcase lubricant oil change / Jet drive lubrication / Throttle and shift linkage lubrication / Steering cable lubrication / Swivel shaft and tilt tube lubrication / Title lock mechanism lubrication / Bearing carrier lubrication / Maintenance / Propeller shaft and propeller maintenance / Cooling system maintenance / Flushing the cooling system / Battery maintenance / Starter maintenance / Fuel requirements / Fuel additives / Fuel filter service / High-pressure fuel pump maintenance / Drive belt inspection / Pump oil level check / Changing the pump oil / Fuel hoses and clamps/ Corrosion prevention / Storage / Submersion / Tune-up / Compression check / Spark plugs / Timing adjustment / Throttle position sensor (TPS) adjustment / Carburetor adjustment / Engine break-in / Specifications
CHAPTER FOUR / TIMING, SYNCHRONIZATION AND ADJUSTMENT
Timing, synchronization and adjustment / Synch and link (80 jet, 105 jet and 115-200 hp [except EFI and HPDI models]) / Synch and link (150-250 hp [EFI and HPDI models]) / Miscellaneous adjustments / Specifications
CHAPTER FIVE / FUEL SYSTEM
Fuel system safety and general information / Fuel tanks / Primer bulb / Fuel hoses / Fuel hose connector / Fuel pumps / Fuel filters / Vapor separator tank / Silencer cover, fuel rail and injectors (EFI and HPDI models) / Throttle body / High pressure mechanical fuel pump / Carburetor and silencer cover / Reed housing/intake manifold / Specifications
CHAPTER SIX / ELECTRICAL AND IGNITION SYSTEMS
Battery / Starting system components / Charging system / Ignition system / Sensors, switches and relays / Warning system components / Specifications
CHAPTER SEVEN / POWER HEAD
Power head preliminary information / Service consideration / Power head break-in / Service recommendations / Lubricants, sealants and adhesives / Sealing surfaces / Fasteners and torque / Power head removal/installation / Flywheel / Power head disassembly / Power head components cleaning and inspection / Power head assembly / Specifications
CHAPTER EIGHT / GEARCASE
Gearcase operation / Propeller removal/installation / Gearcase removal/installation / Water pump / Gearcase repair / Gearcase disassembly (standard RH rotation gearcase) / Component inspection / Gearcase assembly (standard RH rotation gearcase) / Shim selection (all models) / Counter rotation (LH) gearcases / Gearcase pressure test / Specifications
CHAPTER NINE / JET DRIVE
Jet drive operation / Jet drive mounting height / Jet drive repair / Specifications
CHAPTER TEN / POWER TILT/TRIM
Hydraulic tilt/trim system removal and installation / Tilt/trim relay replacement / Tilt/trim sender replacement / Electric tilt/trim motor removal and installation / Tilt/trim system electric motor repair / Manual release valve removal and installation / Hydraulic system filling and bleeding / Specifications
CHAPTER ELEVEN / MIDSECTION
Midsection / Specifications
CHAPTER TWELVE / OIL INJECTION SYSTEM
Oil injection system operation / Oil injection system / Specifications
CHAPTER THIRTEEN / REMOTE CONTROL
Remote control / Specifications
INDEX
COLOR WIRING DIAGRAMS
