Suzuki GSX1300R HAYABUSA (1999-2007) Repair Manual Clymer Reparaturanleitung

This Suzuki Hayabusa Manual is 440 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Engine starting / Engine will not start / Engine performance / Lubrication system / Leakdown test / Clutch / Gearshift linkage / Transmission / Fuel system / Fuel pump / Electrical testing / Electrical systems / Steering and suspension / Brake system / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance intervals shedule / Tune-up / Ignition timing / Valve clearance / Spark plugs / Engine oil and filter / Engine oil pressure / Throttle cable free play / Idle speed adjustment / Fast idle speed / Throttle body synchronization / Fuel line inspection / Emission control systems / Control cable / Fasteners / Specifications

CHAPTER FOUR / ENGINE UPPER END
Cylinder head cover / Camshaft / Cam chain tensioner / Cam chain and chain guides / Cylinder head / Valve lifters and shims / Valves and valve components / Cylinder block / Piston and piston rings / Specifications

CHAPTER FIVE / ENGINE LOWER END
Engine service notes / Engine / Starter idler gear / Starter clutch and gears / Alternator cover / Flywheel / Oil pump / Oil cooler / Oil catch tank / Oil pan and strainer / Crankcase / Balancer / Crankshaft / Connecting rod / Engine break-in / Specifications

CHAPTER SIX / CLUTCH
Clutch bleeding / Draining the system / Clutch cover / Clutch master and slave cylinder / Clutch hose replacement / Specifications

CHAPTER SEVEN / TRANSMISSION, SHIFT MECHANISM AND ENGINE SPROCKET
Engine sprocket cover / Engine sprocket / Shift pedal / External and internal shift mechanism / Specifications

CHAPTER EIGHT / AIR, FUEL INJECTION, EXHAUST AND EMISSIONS SYSTEMS
Depressurizing the fuel system / Fuel tank / Fuel pump / Fuel level sender / Fuel pump relay / Pressure regulator / Air filter housing / Intake air control system / Heat shield / Throttle bodies / Fuel injector / Throttle position TP sensor / Throttle cable replacement / Fast idle choke / Atmospheric pressure AP sensor / Camshaft position sensor / Engine coolant temperature ECT sensor / Intake air pressure IAP sensor / Intake air temperature IAT sensor / Tip over TO sensor / Exhaust system / Evaporative emissions control system / Crankcase breather / Fuel injection self-diagnosis / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Fuel system and cooling / Electrical basics / Electrical connectors / Battery / Charging system / Voltage regulator / rectifier / Stator assembly / Ignition system / Crankshaft position CKP sensor / Engine control module ECM / Ignition coil / plug cap / Ignition switch / Starting system / Starter motor / Starter relay / Sidestand / Gear position GP sensor / Turn signal / Lighting / Horn / Meter assembly / Speed sensor / Oil pressure switch / Switches / Wiring diagrams / Specifications

CHAPTER TEN / COOLING SYSTEM
Inspection / Coolant reservoir / Radiator / Thermo switch / Radiator fan / Radiator fan relay / Engine coolant temperature sensor / Thermostat / Water jacket fitting / Water pump / Specifications

CHAPTER ELEVEN / WHEELS, TIRES AND DRIVE CHAIN
Front and rear wheel and hub / Bearing inspection / Rear coupling and rear sprocket / Drive chain / Specifications

CHAPTER TWELVE.FRONT SUSPENSION AND STEERING
Handlebar / Grips / Handlebar holder / Steering head and stem / Steering head bearing race / Steering stem bearing race / Steering damper / Front fork / Specifications

CHAPTER THIRTEEN / REAR SUSPENSION
Shock absorber / Suspension linkage / Swing arm / Bearing / Specifications

CHAPTER FOURTEEN / BRAKES
Brake bleeding and fluid draining / Brake pads / Front and rear brake caliper / Front and rear master cylinder / Brake pedal / Footpeg / Brake disc / Brake hose / Specifications

CHAPTER FIFTEEN / BODY AND FRAME
Seat / Tail cover / Mirror / Fairing / Upper panel / Center panel / Intake duct / Front and rear lower panel / Fender / Sidestand / Specifications

INDEX

Clymer Reparaturanleitungen zählen zu den erfolgreichsten auf dem Markt und sind sowohl für Hobbyschrauber als auch für Mechaniker der unverzichtbare Ratgeber bei allen Fahrzeugreparaturen. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

Written from hands-on experience gained from the complete strip-down and rebuild of the car, Clymer can help you understand, care for and repair your car. We do it ourselves to help you do-it-yourself, and whatever your mechanical ability, the practical step-by-step explanations, linked to over 900 photos, will help you get the job done right. Regular servicing and maintenance can help maintain its resale value, save you money, and make it safer to drive.

Sprache: Englisch

Gerne stellen wir Ihnen beim Kauf dieses Artikels das 32-seitige technische Wörterbuch von Haynes (englisch/deutsch) als Download zur Verfügung.
