Kawasaki KX80, KX85, KX100 (89-16) Repair Manual Haynes Reparaturanleitung
| eTitel | Kawasaki KX80, KX85, KX100 (89-16) Repair Manual Haynes Reparaturanleitung |
|---|---|
| Seitenzahl | 352 |
| Artikelzustand | Neu |
| Artikelart | Reparaturanleitung |
| Sprache | Englisch |
| Druckvariante Printversion | Printversion in S/W |
| Hersteller | Kawasaki |
| Modelle | strong>KX80 (1991-2000) KX85 (2001-2016) KX85-II (2001-2016) KX100 (1989-2016) See Clymer Manual M444 for 1983-1990 KX80 models. |
| Baujahre | 1989 - 2016 |
| Verlag | Clymer Service Manuals |
| Behandelte Reparaturgruppe | Gesamtes Fahrzeug |
This Kawasaki Manual is 352 pages.
QUICK REFERENCE DATA
CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Basic service methods / Serial numbers / Fasteners / Shop supplies / Basic tools / Precision measuring tools / Storage / Specifications
CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Starting the engine / Starting difficulties / Engine performance / Engine / Leak down test / Fuel system / Electrical troubleshooting / Clutch / External shift mechanism ans transmission / Kickstarter / Drive train noise / Front suspension and steering / Rear suspension / Frame noise / Brakes
CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Service intervals / Tune-up / Pre-ride inspection / Engine lubrication / Oil level check / Transmission oil / Air filter / Spark plug / Fuel system / Exhaust system / Cooling system / Engine compression test / Ignition timing / Control cable lubrication / Throttle cable operation / Clutch cable / Engine top end inspection / Kick pedal and shift pedal / Brakes / Drive chain and sprockets / Tires and wheels / Wheel bearings / Steering / Front fork / Rear shock absorber / Rear swing arm and linkage / General lubrication / Fasteners / Storage / Specifications
CHAPTER FOUR / ENGINE TOP END
Cleanliness / Exhaust system / Cylinder head / Cylinder / KIPS exhaust valve / Piston, piston pin and piston ring / Reed valve assembly / Engine break-in / Specifications
CHAPTER FIVE / ENGINE LOWER END
Servicing engine in frame / Engine / Crankcase and crankshaft / Specifications
CHAPTER SIX / CLUTCH, KICKSTARTER AND EXTERNAL SHIFT MECHANISM (1989-1997 MODELS)
Right crankcase cover / Clutch / Primary drive pinion gear / Clutch cable / Kickstarter / External shift mechanism / Specifications
CHAPTER SEVEN / CLUTCH, KICKSTARTER AND EXTERNAL SHIFT MECHANISM (1998-ON MODELS)
Clutch cover / Clutch release lever / Right crankcase cover / Exhaust valve governor / Clutch / Clutch inspection / Primary drive pinion gear / Clutch cable / Kickstarter / External shift mechanism / Specifications
CHAPTER EIGHT / TRANSMISSION AND INTERNAL SHIFT MECHANISM
Transmission operation / Transmission troubleshooting / Transmission overhaul / Internal shift mechanism / Transmission gear ratios / Specifications
CHAPTER NINE / FUEL SYSTEM
Air filter / Carburetor identification / Carburetor service / Float height adjustment / Fuel level adjustment / Carburetor rejetting / Fuel tank / Fuel shutoff valve / Throttle cable / Airbox / Specifications
CHAPTER TEN / IGNITION SYSTEM
Electrical component replacement / Capacitor discharge ignition / Flywheel / Stator plate assembly / Pickup coil / Capacitor discharge ignition module / Ignition coil / Engine stop switch / Ignition timing / Specification
CHAPTER ELEVEN / COOLING SYSTEM
Cooling system inspection / Radiator / Water pump / Hoses / Specifications
CHAPTER TWELVE / WHEELS, TIRES AND DRIVE CHAIN
Bike stand / Front wheel / Rear wheel / Wheel service / Front hub / Rear hub / Tire changing / Tire repairs / Sprocket replacement / Drive chain / Specifications
CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING (CONVENTIONAL FORK)
Handlebar / Steering head / Front fork / Specifications
CHAPTER FOURTEEN / FRONT SUSPENSION AND STEERING (CARTRIDGE FORK)
Handlebar / Steering head / Front fork / Front fork oil refilling / Front fork adjustment / Specifications
CHAPTER FIFTEEN / REAR SUSPENSION
Rear shock absorber / Rear swing arm / Uni-Trak linkage / Specifications
CHAPTER SIXTEEN / BRAKES
Brake fluid selection / Brake service / Brake pad replacement / Front caliper / Rear caliper / Front master cylinder / Rear master cylinder / Brake hose replacement / Brake disc / Draining brake fluid / Brake bleeding / Rear brake pedal / Specifications
INDEX
WIRING DIAGRAMS
Models covered:
1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 Kawasaki KX100 KX 100
1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 Kawasaki KX80 KX 80
2001-2016 Kawasaki KX85 and KX85-II KX 85
