Honda VT500 (83-88) Repair Manual Clymer Reparaturanleitung

This Honda motorcycle manual is 272 pages.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Service hints / Torque specifications / Safety first / Special tips / Expendable supplies / Serial numbers / Tune-up and troubleshooting tools

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Emergency troubleshooting / Engine starting / Engine performance / Engine noises / Excesive vibration / Front suspension and steering / Brake problems

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine checks / Pre-checks / Service intervals / Tires and wheels / Crankcase breather hose (U.S. models only) / Evaporation emission control (1984 California models only) / Battery / Periodic lubrication / Engine oil and filter change / Final drive oil change / Fork oil change / Control cable lubrication / Periodic maintenance / Air filter cleaning replacement / Fuel strainer cleaning / Steering head adjustment / Tune-up / Valve clearance adjustment / Specifications

CHAPTER FOUR / ENGINE
Engine principles / Servicing engine in frame / Engine removal/installation / Cylinder head cover and camshaft / Cylinder heads / Valves and valve components / Rocker arm assemblies / Cylinder / Piston, piston pin and piston rings / Oil pump drive sprockets and drive chain / Oil pump / Oil pressure relief valve / Primary drive gear / Crankcase and crankshaft / Connecting rods / Output gear case / Alternator rotor starter clutch assembly and gears / Break-in procedure / Specifications

CHAPTER FIVE / CLUTCH AND TRANSMISSION
Clutch operation / Clutch / Clutch cable / External shift mechanism / Transmission / Internal shift mechanism / Specifications

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Carburetor operation / Carburetor service / Carburetor adjustments / Throttle cable replacement / Choke cable replacement / Fuel shutoff valve / Fuel tank / Crankcase breather system (U.S. only) / Evaporative emission control system (1984 California models only) / Exhaust system / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system / Alternator / Voltage regulator/rectifier / Ignition system / Spark unit / Ignition coil / Pulse generator / Starting system / Starter / Starter solenoid / Clutch diode / Lighting system / Switches / Electrical components / Specifications

CHAPTER EIGHT / COOLING SYSTEM
Cooling system check / Radiator / Cooling fan / Thermostat / Water pump / Coolant pipes / Hoses / Specifications

CHAPTER NINE / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheel balance / Tire changing / Tire repairs / Handlebar / Steering head and stem / Steering head bearing races / Front fork / Specifications

CHAPTER TEN / REAR SUSPENSION AND FINAL DRIVE
Rear wheel / Rear hub / Final drive unit and drive shaft / Universal joint / Swing arm / Shock absorbers / Specifications

CHAPTER ELEVEN / BRAKES
Front disc brakes / Front master cylinder / Front brake pad replacement / Front caliper / Front brake hose replacement / Front brake disc / Bleeding the system / Rear drum brake / Rear brake pedal / Specifications

CHAPTER TWELVE / FRAME
Kickstand (sidestand) / Centerstand / Footpegs / Seat / Rear fender / Frame / Specifications

SUPPLEMENT / ADDITIONAL UK INFORMATION
Exhaust system / Front wheel / Front brake pad replacement / Front caliper / Specifications

INDEX

WIRING DIAGRAMS

Models covered:
1983 1984 1985 1986 HONDA VT500C SHADOW
1983 1984 1985 1986 1987 1988 HONDA VT500E Euro Sport
1983 1984 HONDA VT500FT ASCOT

Clymer Manuals Honda VT500C Shadow Manual
Clymer Manuals Honda VT500E Euro Sport Manual
Clymer Manuals Honda VT500FT Ascot Manual

Clymer Reparaturanleitungen zählen zu den erfolgreichsten auf dem Markt und sind sowohl für Hobbyschrauber als auch für Mechaniker der unverzichtbare Ratgeber bei allen Fahrzeugreparaturen. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

Written from hands-on experience gained from the complete strip-down and rebuild of the car, Clymer can help you understand, care for and repair your car. We do it ourselves to help you do-it-yourself, and whatever your mechanical ability, the practical step-by-step explanations, linked to over 900 photos, will help you get the job done right. Regular servicing and maintenance can help maintain its resale value, save you money, and make it safer to drive.

Sprache: Englisch

Gerne stellen wir Ihnen beim Kauf dieses Artikels das 32-seitige technische Wörterbuch von Haynes (englisch/deutsch) als Download zur Verfügung.
